330130-085-01-05 Bently

I. Product Introduction
Bently 330130-085-01-05 is a high-precision non-contact eddy current probe launched by Bently Nevada, a U.S.-based brand. As a core monitoring product of the 330130 series, it is specifically designed for shaft vibration, axial displacement and position monitoring of rotating machinery, serving as a core sensing component in condition monitoring systems for critical equipment in power, petrochemical, metallurgical and other industries. Based on the mature eddy current induction principle, this probe can accurately collect data such as radial vibration and axial movement of the rotating shaft without contacting the measured part, featuring high sensitivity, excellent measurement accuracy and strong anti-interference capability. It can real-time capture subtle state changes during equipment operation, providing reliable data support for predictive maintenance and fault early warning of equipment. With an industrial-grade reinforced sealed structure and a protective design resistant to high and low temperatures and oil pollution, it is suitable for harsh industrial environments with high temperature, high vibration and heavy dust. It can be seamlessly compatible with Bently 3300 and 3500 series monitoring frames, and is widely used in turbines, generators, compressors and other rotating equipment, effectively avoiding equipment failures, extending service life and reducing operation and maintenance costs.

II. Technical Parameters
1. Basic Information
– Brand: Bently Nevada
– Model: 330130-085-01-05
– Product Type: Non-contact Eddy Current Vibration/Displacement Probe
– Origin: USA
– Certification: Compliant with IEC and ANSI industrial standards, with CE certification, meeting explosion-proof and anti-electromagnetic interference industrial specifications
2. Power Supply & Output
– Operating Voltage: -24VDC (typical), compatible with -18VDC to -30VDC wide voltage range
– Output Signal: -1VDC to -17VDC voltage signal, linearly corresponding to the effective measurement displacement range
– Sensitivity: 7.87V/mm (200mV/mil), ensuring stability and accuracy of signal output
3. Measurement Characteristics
– Measurement Range: 0.25mm to 2.25mm (effective linear displacement range, total 2mm)
– Measurement Accuracy: ±0.33% full scale, maximum error not exceeding ±1%, ensuring accurate data collection
– Probe Diameter: 8mm (compact design, suitable for narrow installation spaces)
– Installation Gap: Recommended installation gap 1.25mm (reference value, adjustable according to the measured metal material)
– Frequency Response: 0Hz to 10kHz, covering the full-band vibration signal of rotating equipment
4. Functional Features
– Non-contact Measurement: No mechanical wear, no impact on normal equipment operation, extending the service life of the probe and equipment
– Material Compatibility: Compatible with various metal workpieces such as steel, cast iron and aluminum, can be put into use without additional calibration
– Fault Self-test: Equipped with open circuit and short circuit fault diagnosis functions, fault signals can be real-time fed back to the monitoring system for quick troubleshooting
– Anti-interference Design: Built-in electromagnetic shielding layer, electromagnetic interference resistance up to EN 55011 standard, stable and undistorted signal in complex industrial environments
5. Installation & Compatibility
– Mounting Method: Threaded installation (standard thread specification), compatible with Bently special mounting brackets, easy to install
– Cable Configuration: Standard high-flexibility PFA insulated shielded cable, minimum bending radius 25.4mm, default length optional, support customized extension
– System Compatibility: Seamlessly compatible with Bently 3300 and 3500 monitoring frames, and also compatible with third-party PLC/DCS/SCADA systems

6. Environmental Ratings
– Operating Temperature: -51℃ to +177℃, extended range up to -52℃ to +204℃, suitable for extreme high-temperature working conditions
– Storage Temperature: -55℃ to +180℃, adapting to harsh storage and transportation environments
– Humidity: 0% to 100% (condensation allowed), can operate stably in high-humidity and damp industrial scenarios
– Vibration/Shock: Compliant with IEC 60068-2-6 (vibration) and IEC 60068-2-27 (shock) standards, vibration resistance grade 20g (10-2000Hz)
– Protection Level: IP67 (probe head), with dustproof, waterproof and oilproof capabilities
7. Typical Applications
– Power Industry: Shaft vibration and axial displacement monitoring of turbines, generators and water turbines
– Petrochemical Industry: Condition monitoring of rotating equipment such as centrifugal compressors, centrifugal pumps and blowers
– Metallurgical Industry: Vibration monitoring and fault early warning of heavy rotating equipment such as rolling mills and motors
– General Industry: Predictive maintenance monitoring of gearboxes, turbines, centrifuges and other equipment
