ABB PPC907BE Industrial Controller Technical Specifications
Model Identification
| Parameter | Value |
|---|---|
| Primary Order Code | 3BHE024577R0101 |
| Hardware Revision | PPC907BE101 (Explosion-Proof Variant) |
| Product Family | AC 800M High-Performance Controllers |
| Firmware Platform | ABB Control Software v4.3+ |
Core Technical Parameters
| Category | Specification |
|---|---|
| Processing | • Dual-Core ARM Cortex-A9 @ 1.2 GHz • 1GB DDR3 RAM (ECC-protected) • 4GB Flash Storage |
| Environmental | • Operating Temp: -40°C to +70°C • Humidity: 5-95% non-condensing • Altitude: ≤ 2000m (derating above) |
| Power Supply | • 24VDC Nominal (18-32VDC range) • 15W max consumption • Class I Div 2/ATEX Zone 2 certified |
| MTBF | 285,000 hours @ 40°C (IEC 61709) |
Interface Configuration
| Interface Type | Technical Details |
|---|---|
| Fieldbus | • 2x PROFINET IRT (3-port switch) • 1x CANopen • 2x RS-485 (Modbus RTU/ASCII) |
| Ethernet | • 2x 10/100BASE-TX (RJ45) • IEEE 1588 PTPv2 Precision Timing |
| Expansion | • 1x SDHC Slot (max 32GB) • 1x USB 2.0 Host • PCIe Mini for comm modules |
| HMI | • 12.1″ XGA TFT (1024×768) • Projected Capacitive Touch • 500 nits brightness |
Certifications & Compliance
| Standard | Certification ID |
|---|---|
| Functional Safety | SIL 2 (IEC 61508), PLd (ISO 13849-1) |
| EMC | EN 61000-6-2/4, FCC Part 15 Class A |
| Hazardous Areas | ATEX II 3G Ex ec nC IIC T4 Gc IECEx Ex ec nC IIC T4 Gc |
| Industry | UL 508/61800-5-1, DNV-GL Marine |
Physical Dimensions
| Attribute | Value |
|---|---|
| Enclosure | IP66/NEMA 4X Stainless Steel (316L) |
| Dimensions | 338 x 258 x 89 mm (W x H x D) |
| Weight | 5.2 kg (11.5 lbs) |
| Mounting | Panel cutout: 322 x 242 mm |
️ Critical Application Notes
-
Redundancy
- Supports hot-standby via fiber-optic sync (ABB S800 I/O)
- Max switchover time: 12ms
-
Firmware Constraints
- Requires ≥v4.1.5 for cybersecurity features (TLS 1.3)
- NOT backward-compatible with PPC905AE firmware
-
Derating Requirements
Above 2000m: -1% current rating/300m
Above 55°C: -2% processing power/°C
3BHE024577R0101 PPC907BE PPC907BE101 ABB PDF
3BHE024577R0101 PPC907BE PPC907BE101 ABB
♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦
