Basic Parameters of ABB 3HNE00313-1 TPU2

General Specifications

• Model Number: 3HNE00313-1
• Product Type: TPU2 Teach Pendant Unit
• Manufacturer: ABB
• Main Application: Serves as a human-machine interface for ABB robot programming, operation, and status monitoring
•

Physical Dimensions

• Overall Size: Ergonomically designed for handheld operation (specific measurements available in official technical documentation)
• Weight: Approximately 1.0 kg (net weight, subject to official confirmation)

Display Screen

• Type: Industrial-grade LCD with backlight
• Characteristics: High contrast and visibility suitable for factory floor environments

Operational Interface

• Input Components: Membrane keypad with dedicated function buttons, directional navigation keys, and an emergency stop switch
• Design: User-friendly layout optimized for efficient robot programming workflows

Connectivity

• Interface: Proprietary ABB communication port for connection to robot controllers
• Cable: Integrated heavy-duty cable with strain relief (standard length compliant with ABB specifications)

Power Supply

• Power Source: Powered via connection to the ABB robot controller
• Voltage: Low-voltage DC (matches the controller’s auxiliary power output specifications)

Environmental Ratings

• Operating Temperature: -10°C to 55°C (industrial environment tolerance)
• Protection Class: IP54 (protects against dust ingress and water splashes from any direction)

Compliance Standards

• Meets relevant IEC and ISO industrial safety standards
• Complies with electromagnetic compatibility (EMC) regulations for industrial equipment

3HNE00313-1 TPU2 ABB pdf

3HNE00313-1

♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦
