750P1G1S1HIA20RE

1. General Information
– Product Name: 750 Series Universal Discrete Input Module
– Model Number: 750P1G1S1HIA20RE
– Brand: GE Fanuc (General Electric)
– Category: Programmable Logic Controller (PLC) Input Module
2. Electrical Characteristics
– Input Type: Alternating Current (AC) Discrete Input
– Input Voltage: 120 VAC
– Input Current: Approximately 10 mA (per point)

– Input Impedance: Approximately 12 kΩ
– Isolation Method: Opto-isolation
– Isolation Voltage: 1500 VAC (for 1 minute)
– Common Mode Rejection: > 1500 V (Peak)
– Differential Mode Rejection: > 100 V (Peak)
3. Performance Parameters
– Response Time: Typical 10 ms (configurable filtering)
– Number of Inputs: 16 Points
– Termination: Screw terminals or Spring terminals (depending on specific sub-model)
– LED Indicators: Status indicator (Green) for each input point

4. Environmental Parameters
– Operating Temperature: 0°C to 60°C
– Storage Temperature: -40°C to 85°C
– Relative Humidity: 5% to 95% (non-condensing)- Vibration: 5 g (5-500 Hz)
– Shock: 30 g (11 ms half-sine)
5. Mechanical Parameters
– Dimensions: Standard 750 Series form factor (Approx. 127 mm H x 35 mm W x 115 mm D)
– Weight: Approximately 0.2 kg
– Mounting: DIN Rail Mount
