ABB PPD115A102 3BHE017628R0102 Generator Protection Relay
Order Code: 3BHE017628R0102
Hardware Revision: H3
Electrical Parameters
| Characteristic | Specification |
|---|---|
| Rated Voltage | 48-250V AC/DC (85-264V AC range) |
| Burden | ≤0.2 VA per current input (1A nominal) |
| Frequency Range | 16.67/50/60 Hz ±10% (auto-tracking) |
| Overload Capacity | 100× In (1s), 250× In (100ms) |
Protection Functions
Core ANSI Codes:
- 27: Under-voltage (0.1-1.5× Un, Δt=0.02-300s)
- 32R: Reverse Power (0.5-20% Pn, dP/dt monitoring)
- 46: Negative Sequence (I₂=5-50% In, k-factor=0.1-10)
- 50/51: Phase OC (0.05-40× In, IDMT curves per IEC 60255)
- 59N: Neutral OV (3U₀=1-200V, transient blocking)
Backup functions: 78PS (Out-of-step), 81O/U (Over/Under freq.)
Measurement Accuracy
| Parameter | Range | Error | Conditions |
|---|---|---|---|
| Voltage | 0.1-1.8× Un | ±0.2% | @ 45-65Hz, 20°C |
| Current | 0.01-4.0× In | ±0.1% | THD < 3% |
| Power | 0.2-150% Pn | ±0.5% | cosφ > 0.5 |
| Frequency | 15-65 Hz | ±5 mHz | U>10% Un |
Communication & I/O
Interfaces:
- Ethernet: 2x 100BASE-TX (IEC 61850-8-1 Ed.2, Modbus TCP)
- RS485: IEC 60870-5-103, DNP3.0
- Binary Inputs: 8× (24-250V DC, opto-isolated)
- Relay Outputs: 6× (5A/250V AC, Form-C)
- RTD Inputs: 6× (Pt100/Pt1000, 3-wire)
Protocol Support:
IEC 61850 (GOOSE/SV), IEC 60870-5-104, PROFINET RT
Environmental & Mechanical
| Parameter | Value |
|---|---|
| Operating Temperature | -25°C to +70°C (derate >55°C) |
| Humidity | 5-95% RH non-condensing |
| Enclosure | IP52 (front), IP20 (rear) |
| Dimensions (W×H×D) | 177 × 218 × 170 mm |
| Mounting | Panel or DIN rail (TS35) |
| Weight | 2.3 kg |
♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦
