- Model: ICSE08B5
- Product Type: Digital Input Module
- Manufacturer: ABB
- Core Function: Receives 24 VDC discrete digital signals from external devices, converts them into standardized digital data, and transmits to the host controller for industrial process control and status monitoring.
- Input Channels: 8 independent digital input channels (isolated between channels to prevent signal interference).
- Input Signal Type: 24 VDC sinking/sourcing input (configurable via DIP switches or software, subject to product version).
- Input Voltage Range:
- Off-state voltage: ≤5 VDC (maximum);
- On-state voltage: 19–30 VDC (typical, compliant with IEC 61131-2 standards).
- Input Current:
- On-state current: 4–10 mA per channel (at 24 VDC);
- Off-state current: ≤1 mA per channel.
- Response Time: ≤1 ms (for signal detection, ensuring real-time data transmission).
- Power Supply: Derived from the connected ABB controller or external 24 VDC power supply (typical: 24 VDC ±10%; power consumption: ≤2 W under full load).
- Dimensions: Compact DIN rail-mount design (typical: Width ≈ 22.5 mm, Height ≈ 100 mm, Depth ≈ 120 mm; confirm exact values with official datasheet).
- Weight: Approximately 0.15–0.25 kg (net weight, excluding cables).
- Protection Class: IP20 (suitable for indoor control cabinet installation; dust-protected, not water-resistant).
- Operating Temperature Range: -25°C to +60°C (wide temperature tolerance for industrial environments).
- Storage Temperature Range: -40°C to +85°C.
- Humidity Resistance: ≤95% RH (non-condensing, no moisture ingress allowed).
- Vibration Resistance: 10–500 Hz, 0.5 g acceleration (compliant with IEC 60068-2-6).
- Shock Resistance: 15 g acceleration (11 ms duration, compliant with IEC 60068-2-27).
- Mounting Method: Standard 35 mm DIN rail mounting (compliant with IEC 60715, for easy integration into control cabinets).
- Compatibility: Primarily designed for ABB AC500 series programmable logic controllers (e.g., AC500-eCo, AC500-S) and compatible with ABB Control Builder Plus software for parameter configuration.
- Wiring Interface: Spring-clamp or screw terminals (recommended wire gauge: 0.5–1.5 mm²; torque for screw terminals: 0.5–0.8 N·m).
- Safety Standards:
- Complies with IEC 61010-1 (safety for electrical equipment in control systems);
- Certified for SIL 2 (Safety Integrity Level) applications (per IEC 61508, for critical control scenarios).
- EMC Compliance:
- Emission: EN 61326-1 (industrial environment);
- Immunity: EN 61326-1 (ESD: ±8 kV contact, ±15 kV air; surge: ±2 kV line-line, ±4 kV line-earth).
