ABB Protection & Control IED
Model: PCD235B1101
Order Code: 3BHE032025R1101
Series: Relion® 670
Core Functions
| Feature | Description |
|---|---|
| Protection | Differential (87L), Overcurrent (51/51N) |
| Control | IEC 61850 GOOSE messaging, Synchrocheck |
| Monitoring | Power quality (THD <2%), Fault recording |
| Communication | Dual Ethernet (IEC 61850-8-1 Ed.2) |
Technical Parameters
Electrical Characteristics
- Input Voltage: 48-250V DC / 100-240V AC
- Binary Inputs: 24V DC (15-30V), 5mA wetting current
- Analog Inputs: 4-20mA (16-bit resolution)
Mechanical Specifications
- Dimensions: 177×177×180mm (W×H×D)
- Weight: 2.3kg
- Mounting: Panel or DIN rail (EN 60715)
Environmental Compliance
- Operating Temp: -40°C to +70°C
- Humidity: 5-95% RH non-condensing
- EMC: IEC 60255-26 (Class A)
Certifications & Standards
- IEC 60255-1 (Measuring relays) - IEEE C37.90 (Surge withstand) - UL 508 (Industrial control equipment) - DNV-GL (Marine applications)
♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦
