- Model: RXIDK 2H (Full Model: 1MRK000838-HA)
- Product Type: Relay Interface Module
- Manufacturer: ABB
- Core Function: Provides electrical isolation between input and output signals, converts discrete signals (e.g., from sensors, switches) into controller-compatible formats, and supports reliable signal transmission in industrial control loops.
- Input Channels: 2 independent input channels (isolated between channels to avoid cross-interference).
- Input Signal Type: Discrete digital input (e.g., 24 VDC, 110 VAC; configurable based on application, subject to product version).
- Input Voltage Range:
- DC Input: 19–30 VDC (typical for 24 VDC rated input);
- AC Input: 85–132 VAC (typical for 110 VAC rated input, if applicable).
- Input Current:
- On-state current: 5–15 mA per channel (at rated DC input);
- Off-state current: ≤1 mA per channel.
- Output Type: Relay output (normally open/normally closed contacts, configurable via wiring).
- Output Contact Rating:
- Maximum Voltage: 250 VAC / 30 VDC (subject to official confirmation);
- Maximum Current: 5 A (resistive load, typical for industrial relay modules);
- Switching Power: ≤1250 VA (AC) / ≤150 W (DC).
- Power Supply: Derived from external industrial power supply (typical: 24 VDC ±10% or 110/230 VAC ±10%; power consumption: ≤3 W under full load).
- Dimensions: Compact panel-mount design (typical: Width ≈ 45 mm, Height ≈ 100 mm, Depth ≈ 120 mm; confirm exact values with official datasheet).
- Weight: Approximately 0.2–0.3 kg (net weight, excluding mounting hardware and cables).
- Protection Class: IP20 (suitable for indoor control cabinet installation; dust-protected, not water-resistant).
- Operating Temperature Range: -25°C to +60°C (wide tolerance for harsh industrial environments).
- Storage Temperature Range: -40°C to +85°C.
- Humidity Resistance: ≤95% RH (non-condensing, no moisture accumulation allowed).
- Vibration Resistance: 10–500 Hz, 0.5 g acceleration (compliant with IEC 60068-2-6).
- Shock Resistance: 15 g acceleration (11 ms duration, compliant with IEC 60068-2-27).
- Mounting Method: Panel mounting via screws (compatible with standard industrial control cabinet panels; recommended mounting torque: 0.8–1.2 N·m).
- Compatibility: Designed for integration with ABB protection relays (e.g., REF615, RET670) and AC500 series PLCs; compatible with ABB Control Builder software for parameter setting (if applicable).
- Wiring Interface: Screw terminals (recommended wire gauge: 0.5–2.5 mm²; suitable for both solid and stranded wires).
- Safety Standards:
- Complies with IEC 61010-1 (safety requirements for electrical equipment in control systems);
- Isolation Rating: 2.5 kV AC (input-output isolation, for electrical safety).
- EMC Compliance:
- Emission: EN 61326-1 (industrial environment, low electromagnetic interference);
- Immunity: EN 61326-1 (ESD: ±8 kV contact, ±15 kV air; surge: ±2 kV line-line, ±4 kV line-earth).
♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦
