ABB TP867 3BSE043664R1 Product Profile & Technical Specifications
One-sentence Overview
ABB TP867 3BSE043664R1 is a termination baseplate designed for ABB AC800M communication modules (CI867, CI868, CI871, CI873, CI874), featuring a robust construction, compact form factor (127.5 × 186 × 59 mm, 0.7 kg), dual RJ45 Ethernet connectors, CEX-Bus interface, and IP20 protection, ensuring reliable mechanical mounting and electrical connection for industrial automation communication interfaces.
1. Basic Product Information
Brand/Manufacturer: ABB Ltd., a global leader in power grid, industrial automation and electrical equipment solutions
Model Number: TP867 (also referred to as Termination Base Unit for Communication Modules)
Part Number: 3BSE043664R1 (Ordering Code: TP867)
Product Series: ABB AC800M System Baseplates
Product Type: Industrial-grade termination baseplate for AC800M communication interface modules
Core Application: Mechanical mounting and electrical connection for ABB AC800M communication modules including CI867 (Modbus TCP), CI868 (PROFIBUS DP), CI871 (PROFINET IO), CI873 (Ethernet/IP), and CI874 (Modbus RTU)
Compliance & Certification: Complies with IEC 61131-2, IEC 60529 international standards; certified with CE, UL, and RoHS for global industrial application
Compatibility: Specifically designed for ABB AC800M controller system; seamlessly integrates with CI867, CI868, CI871, CI873, and CI874 communication modules; provides CEX-Bus interface for power and data transfer between module and controller
Product Status: Brand-new original industrial component, factory-sealed with complete technical documentation and installation instructions
Warranty: 1-year standard factory warranty (extended warranty options available through authorized distributors)
2. Physical Specifications
Weight: Net weight approximately 0.7 kg (1.54 lbs); gross weight including packaging approximately 0.9 kg (1.98 lbs)
Dimensions (L × W × H): Standard baseplate dimensions – Net Depth/Length: 127.5 mm (5.02 in), Net Height: 186 mm (7.32 in), Net Width: 59 mm (2.32 in)
Mounting Method: DIN rail mounting (compatible with standard 35 mm DIN rails); designed for secure installation in industrial control cabinets and automation racks
Housing Material: High-strength industrial-grade plastic with metal reinforcement; durable construction for long-term use in harsh industrial environments
Protection Grade: IP20 according to EN60529, IEC 529 (provides dust protection and prevents accidental contact with internal live parts)
Structural Features: Two RJ45 female (8-pin) Ethernet connectors for communication (Ch1 and Ch2); CEX-Bus connector for module connection; clearly marked terminal points for easy wiring; integrated locking mechanism to secure communication modules; DIN rail clips for stable mounting; ventilation slots for thermal management
