ABB UAD142A01 3BHE012551R0001 Controllers for industry
Panel cutout
Panel cutout to DIN 43 700: 92+0.8mm × 92+0.8mm
With close-packed horizontal mounting:bar width min. 10 mm.
Leave sufficient space above and underneath the units for ventilation: min 40 mm.
Note
The space between the units must not be encroached upon by wiring.
ABB UAD142A01 3BHE012551R0001 Controllers for industry
ABB UAD142A01 3BHE012551R0001 Controllers for industry
1. Remove the blanking caps on the front.
2. Turn the clamping claw screw 1 anti-clockwise until the clamping claws 2 can snap into place behind panel.
3. Push module into the front panel cutout.
4. Turn the clamping claw screw 1 clockwise until the clamping claws 2 snap into place behind the panel and module is firmly fixed.
5. Replug the blanking caps.
ABB UAD142A01 3BHE012551R0001 Controllers for industry
ABB UAD142A01 3BHE012551R0001 Controllers for industry
All four inputs of one module can only be operated under the same measuring task.With incremental measurement, the direction of rotation/movement is recognized. For this, two inputs are linked to form one input.
With incremental measurement with zero recognition, the direction of rotation/movement is recognized and the measurement input is set to zero via a third input, if this input is set. Thus, an absolute displacement/angular position measurement is possible.For this, three inputs are linked to form one input. In this case,the fourth input can not be used.
ABB UAD142A01 3BHE012551R0001 Controllers for industry
♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦
Shipping:
1. Your item will be shipped to all countries via EMS, unless one country cannot be shipped via EMS. We will choose DHL, UPS, or FedEx. Please leave us your phone number.
2. We will ship the product to you on the same day or within 1-2 working days after receiving your payment. The shipping time depends on the country/region where you reside, the customs and habits of your country/region, and especially during peak hours.
3. Assuming (assuming) that the item requires payment of tariffs from your country, the buyer is obligated. We are not responsible for any taxes or customs fees in your country/region.
