The ACS580-01-07A3-4 is a general-purpose AC drive from ABB’s ACS580 series, designed for energy-efficient speed control of AC induction motors in industrial and commercial applications.
- Series: ABB ACS580 (low-voltage general-purpose AC drive)
- Configuration: Standalone, wall-mounted (or cabinet-mounted) design
- Target Motor Type: Three-phase AC induction motors
- Key Feature: Integrated energy-saving algorithms, user-friendly parameter setting, and wide environmental adaptability
- Supported Control Modes:
- V/F Control (Voltage/Frequency Control): Suitable for fans, pumps, and other constant-torque or variable-torque loads.
- Sensorless Vector Control: Enables high starting torque (150% of rated torque at 0.5 Hz) and precise speed regulation (speed accuracy: ±0.5% of rated speed).
- Flux Vector Control (optional with encoder feedback): Achieves higher speed accuracy (±0.01% of rated speed) for high-precision applications (e.g., conveyors, mixers).
- Speed Regulation Accuracy:
- ±0.5% (sensorless vector mode, no encoder)
±0.01% (flux vector mode, with incremental encoder)
- Torque Response Time: ≤100 ms (for torque step changes in vector control mode)
- Dimensions (W × H × D): Approx. 110 mm × 210 mm × 175 mm (without optional accessories)
- Weight: Approx. 2.5 kg
- Protection Degree (IP Rating): IP20 (standard; suitable for installation inside control cabinets or clean, dust-free environments)
- Cooling Method: Forced air cooling (built-in fan with temperature-controlled speed)
- Operating Temperature Range:
- 0–40 °C (no derating required)
40–50 °C (derating by 2.5% per °C above 40 °C)
- Storage Temperature Range: -40–70 °C
- Relative Humidity: 5–95% (non-condensing; no dew formation allowed)
- Altitude: ≤1000 m (above sea level; derating by 1% per 100 m above 1000 m, up to 4000 m)
- Vibration Resistance: ≤5.9 m/s² (10–500 Hz, according to IEC 60034-1)
- Safety Functions: Built-in Safe Torque Off (STO) function, conforming to EN ISO 13849-1 (PL d) and IEC 61508 (SIL 2) standards.
- Compliance Certifications: CE (EU), UL (US), cUL (Canada), CSA (North America), CCC (China), and RoHS (restriction of hazardous substances).
- Built-in Communication Protocols: Modbus RTU (RS-485 port), BACnet MS/TP (for building automation).
- Optional Communication Modules: Profinet, EtherNet/IP, DeviceNet, LonWorks, and Modbus TCP (via plug-in fieldbus cards).
- I/O Terminals:
- Digital Inputs: 6 (configurable, 24 V DC)
- Digital Outputs: 2 (relay outputs, 250 V AC/30 V DC, 5 A)
- Analog Inputs: 2 (1×0–10 V DC, 1×0–20 mA DC; configurable)
- Analog Outputs: 1 (0–20 mA DC; configurable for speed, current, or torque feedback)
