Technical Specifications of AI02J

1. Core Function & Type

• Type: 2-channel analog input module (isolated)
• Purpose: Converts analog input signals (voltage/current) to digital data for integration with ABB drives (e.g., ACS880, ACS580 series) and PLC systems

2. Input Specifications

3. Performance Characteristics

• Accuracy: ±0.1% of full scale (at 25 °C; including linearity, hysteresis, and repeatability errors)
• Resolution: 16-bit (digital conversion)
• Response Time: ≤10 ms (90% of step input)
• Temperature Drift: ≤0.01% of full scale/°C (over 0–50 °C)

4. Compatibility

• Compatible Drives: ABB ACS880, ACS580, and ACS480 series AC drives
• Connection: Via dedicated terminal block (screw-type, 0.5–2.5 mm² wire)
• Communication: Integrates with drive control board via internal signal bus (no external communication protocol required)

5. Environmental & Physical Properties

• Operating Temperature: -25 °C to +70 °C
• Storage Temperature: -40 °C to +85 °C
• Relative Humidity: 5–95% (non-condensing)
• Vibration Resistance: 10–500 Hz, 10 m/s² (IEC 60068-2-6)
• Shock Resistance: 30 g, 11 ms (half-sine wave; IEC 60068-2-27)
• Protection Rating: IP20 (when mounted inside a drive or control cabinet)
• Dimensions (W × H × D): Approx. 45 mm × 80 mm × 30 mm
• Weight: Approx. 50 g

6. Electrical Requirements

• Power Supply: Derived from the host drive (no external power needed)
• Power Consumption: ≤1 W
