ALCL-15-7 ABB

Core Functions & Features

• Harmonic Mitigation: Reduces harmonic distortion generated by AC drives, minimizing interference with other equipment on the same power grid (e.g., PLCs, sensors, and communication systems).
• Voltage Spike Suppression: Dampens transient voltage spikes and surges from the mains supply, protecting the drive’s input rectifier and semiconductor components from damage.
• Power Factor Improvement: Optimizes the input power factor of the drive system, reducing reactive power consumption and improving overall energy efficiency.
• Smooth Current Waveform: Filters the input current to reduce ripple, extending the service life of capacitors and other passive components in the drive.
•

Key Specifications

• Rated Current: 15 A (continuous operation at 40 °C ambient temperature)
• Rated Voltage: 400 V AC (3-phase, 50/60 Hz; compatible with 380–480 V AC grids with ±10% tolerance)
• Inductance: Typically 7 mH (at rated current, ensuring effective filtering performance)
• Insulation Class: F (withstands temperatures up to 155 °C)
• Cooling Method: Natural convection (no external fans required)

Compatibility & Installation

• Compatible Drives: Seamlessly integrates with ABB ACS580 (0.75–3 kW) and ACS480 (0.37–3 kW) series AC drives, as well as other low-power 3-phase drives.
• Mounting: Compact, DIN-rail or panel-mounted design, saving space in control cabinets.
• Protection: IP00 rating (suitable for installation inside enclosed control cabinets; protected against dust ingress).

Typical Applications

• Small-scale industrial machinery (e.g., food processing conveyors, packaging equipment)
• HVAC systems (fans, pumps in commercial buildings)
• Water treatment plants (small booster pumps)
• Renewable energy systems (auxiliary motor drives in solar/wind installations)
