1. Basic Parameters
It is a general – purpose equipment monitor with an protection class of IP67. The power supply supports 24V DC and can also be equipped with an optional 110/220V AC external power supply. The operating temperature range is from -40°C to +85°C.
2. Input – related
It includes 4 vibration input channels and 4 temperature input channels. The vibration input is compatible with 2 – wire and 3 – wire accelerometers, velocity sensors and other sensors. The temperature input is compatible with type E, J, K and T thermocouples as well as 2 – wire or 3 – wire RTDs, and the vibration measurement frequency range is 0.5Hz to 1kHz.
3. Output – related
It is equipped with 6 relay outputs, 4 4 – 20mA recorder outputs and a dedicated buffered output, which can provide signals for each sensor input.
4. Other Performances
It is equipped with a 24 – bit ADC converter, and the measurement accuracy is ±0.5%. It supports Modbus communication through Ethernet and a software – configurable RS232/485 serial port. It supports an optional display and keypad, which can be installed up to 75 meters away from the monitor module. Configuration information can be permanently stored in non – volatile memory.
