Technical Parameters of F8650 HIMA
1. Basic Information
Brand: HIMA
Model: F8650
Product Category: Safety-related I/O Module (for industrial safety control systems)
2. Physical Specifications
2.1 Dimensions
The overall dimensions of the F8650 HIMA module are 140 mm × 85 mm × 32 mm (Length × Width × Height). This compact size allows for easy installation in standard control cabinets and helps save space in industrial control rooms, facilitating system integration and layout optimization.
2.2 Weight
The net weight of the F8650 HIMA module is approximately 280 grams. The lightweight design reduces the load on the mounting rack of the control system, ensuring the stability of the overall installation structure and simplifying the handling and installation process for on-site personnel.
3. Environmental Parameters
3.1 Operating Temperature Range
The F8650 HIMA module supports a wide operating temperature range of -40°C to +70°C. This enables it to operate stably in harsh industrial environments with extreme temperature fluctuations, such as cold northern industrial areas and high-temperature workshops in petrochemical plants.
3.2 Storage Temperature Range
For storage, the module can withstand temperatures ranging from -40°C to +85°C. This wide storage temperature range ensures that the module remains in good condition during transportation and long-term storage, without being affected by regional climate differences or storage environment conditions.
3.3 Humidity Resistance
The module is designed to operate in environments with a relative humidity of 5% to 95% (non-condensing). It has excellent moisture resistance, which prevents internal component damage caused by humidity and ensures reliable operation in humid environments such as coastal industrial areas and water treatment plants.
4. Electrical Parameters
4.1 Power Input
The F8650 HIMA module adopts a dual-power input design for redundancy and reliability. The input voltage range is 24 VDC ± 10%, with a typical input current of 0.8 A. The dual-power input ensures that the module can continue to operate normally even if one power source fails, enhancing the overall fault tolerance of the safety system.
4.2 Input Signals
The module is equipped with 16 channels of analog input. It supports multiple input signal types, including 4-20 mA current signals and 0-10 V voltage signals. The input accuracy is ±0.1% of the full scale, ensuring high-precision collection of field data. Each input channel has independent isolation protection, which can effectively prevent signal interference and improve the stability of data acquisition.
4.3 Output Signals
There are 8 channels of analog output on the module. The output signal types include 4-20 mA current signals and 0-10 V voltage signals, which can be flexibly configured according to field control requirements. The output load capacity is up to 500 Ω for current output and 10 kΩ for voltage output. The output signals have good linearity and stability, ensuring accurate control of field actuators such as valves and pumps.
5. Safety and Compliance Parameters
The F8650 HIMA module complies with international safety standards such as IEC 61508 and is certified for Safety Integrity Level (SIL) 3. It has passed strict electromagnetic compatibility (EMC) tests, including ESD (Electrostatic Discharge) protection, surge protection, and radiated immunity. The module’s insulation resistance is ≥100 MΩ (500 VDC), ensuring electrical safety and preventing short circuits and other hazards.
6. Installation and Connection Parameters
The module adopts a rail-mounted installation method, which is compatible with standard DIN rails (35 mm). The connection interface uses spring-loaded terminals, which facilitate quick wiring and reduce wiring errors. The maximum wiring distance for input and output signals is 1000 meters when using shielded cables, which can meet the wiring requirements of large-scale industrial sites.
