FDC280 RH101FQ BY FOXBORO

FDC280 RH101FQ BY FOXBORO

This FBM is a generic Ethernet hardware module in which different software drivers can be loaded. These drivers configure the FBM to recognize a particular protocol used by the device. Several of these software drivers are a standard product offerings.Other custom drivers can be developed to meet specific needs. These drivers are dynamically downloaded to the FDC280 RH101FQ with software code specifically designed to interface with the third party device’s protocol.The configuration procedures and the software requirements for each driver are unique to the device(s) being integrated into the system.                                                                                                                                                                                                                                                                                                                                                      FDC280 RH101FQ BY FOXBORO

FDC280 RH101FQ BY FOXBORO                                                                                                                                                                                                                                                                                                                                                                                                              Each FDC280 RH101FQ pair can access up to 64 devices to read or write data.From the I/A Series control station to which the FDC280 RH101FQ is connected (refer to Figure 1), up to 2000 Distributed Control Interface (DCI) data connections can be made to read or write data. Supported data types are determined by the particular driver loaded on the FDC280 RH101FQ, which converts the data to the DCI data types listed below:
 An analog input or output value (integer or IEEE single-precision floating point)
 A single digital input or output value
 Multiple (packed) digital input or output values (packed in groups of up to 32 digital points per connection).
Thus an I/A Series control station can access up to 2000 analog I/O values, or up to 64000 digital I/O values, or a combination of digital and analog values using the FBM233. The frequency of access to the FBM233 data by a control station can be as fast as 500 ms. The performance is dependant on each device type and the layout of data in the device.                                                                                                                                                                                                                                                                                                                         FDC280 RH101FQ BY FOXBORO

FDC280 RH101FQ BY FOXBORO

The FDC280 RH101FQ collects the required data from the devices, performs the necessary conversions, and then stores the converted data in its database for incorporation into the I/A Series plant management functions and operator displays. Data may also be written out to the individual devices from the I/A Series system.The FDC280 RH101FQ has a compact design, with a rugged extruded aluminum exterior for physical and electrical protection of the circuits. Enclosures, specially designed for mounting the FBMs, provide various levels of environmental protection, up to Class G3 harsh environments per ISA Standard S71.04.
FDC280 RH101FQ BY FOXBORO PDF

FDC280 RH101FQ BY FOXBORO

The redundancy of the module pair, coupled with the high coverage of faults, provides very high subsystem availability time.Either module may be replaced without upsetting field input or output signals to the other module. A module can be removed or replaced without removing power to the other FBM modules in the Modular Baseplate.The 4-Port 10 Mbps Industrial Hubs are DIN rail mounted and support 10 Mbps Ethernet protocol to/from devices that communicate at speeds of 10 Mbps. You can connect up to three dual-ported Ethernet devices, using a pair of hubs, to a redundant FDC280 RH101FQ. Multiple hubs can be interconnected to connect up to 64 devices to the FDC280 RH101FQ.                                                                                                                                                                                       FDC280 RH101FQ BY FOXBORO

♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦
