The NCS125/165 sensor is entirely symmetrical. Its square shape and strategically positioned oblong holes make it easy to fasten in a choice of 2 positions.As an accessory it comes with a side plate that can be fastened on either side of the sensor giving complete fitting flexibility. It meets the standard design of ABB current sensors. It can be fitted both horizontally and vertically. This flexibility means that NCS125/165 sensor simplifies the
work of integrators. Additionally the pair of side plate allows the NCS125/165 sensor to be fitted to one or several bars at the same time.The NCS305 sensor has been designed to reduce installation
costs for new and retrofit systems. Using our innovative and robust opening, the clip-on system allows the NCS305 to be easily adapted to existing bus bars.
GDB021BE05 HIEE300766R0005 IN STOCK
GDB021BE05 HIEE300766R0005 IN STOCK
General data
– Coated electronic circuit.
– Plastic case and insulating resin are self-extinguishing.
– Direction of the current: A positive primary differential voltage
(UHT+ – UHT- > 0) results in a positive secondary output current
from terminal M.
– Protections:
– of the measuring circuit against short-circuits.
– of the measuring circuit against opening.
– of the power supply against polarity reversal.
– Burn-in test in accordance with FPTC 404304 cycle.
– Tightening torque for M5 terminal studs (N.m): 2 N.m.
GDB021BE05 HIEE300766R0005 IN STOCK
GDB021BE05 HIEE300766R0005 IN STOCK
Utilisation
Sensors to measure DC or AC voltages with a galvanic insulation between primary and secondary circuits.The input resistor RE is included with calibrated EM010 sensors, the voltage to be measured UP can be applied directly to the primary terminals marked “+HT” and “-HT” (see diagram below).
Primary connection
– Insert M5x7 for terminals HT1+ and HT2+
– Insert M4x7 for terminals HT1- and HT2
UOFF : Low limit at which the LEDs extinguish when the equipment is electrically isolated.
UON : High limit at which the LEDs illuminate (flashing frequency approximately 2 Hz) when the equipment power is switched on.Between these two limits the LEDs maybe extinguished or flashing.
