GDC806A0101 3BHE028761R0101 ABB NEW AND ORIGINAL
This module has 16 digital inputs. The input signal voltage range is 36 to 60 volt d.c. and the input current is 4 mA at 48 V. The inputs are divided into two individually isolated groups with eight channels and one voltage supervision input in each group. Every input channel consists of current limiting components, EMC protection components, input state indication LED and optical isolation barrier. The process voltage supervision input give channel error signals if the voltage disappears. The error signal can be read via the ModuleBus.
GDC806A0101 3BHE028761R0101 ABB NEW AND ORIGINAL
GDC806A0101 3BHE028761R0101 ABB NEW AND ORIGINAL
Features and benefits
1.16 channels for 48 V d.c. inputs with current sinking
2.2 isolated groups of 8 with voltage supervision
3.Input status indicators
GDC806A0101 3BHE028761R0101 ABB NEW AND ORIGINAL
Detailed data
Input voltage range, “0” -60 .. +10 V
Input voltage range, “1” 30 .. 60 V
Input impedance 11 kΩ
Isolation Groupwise isolated from ground, 2 groups with 8 channels
Filter times (digital, selectable) 2, 4, 8, 16 ms
Current limiting Sensor power can be current limited by the MTU
Maximum field cable length 600 meters (656 yards)
Rated insulation voltage 50 V
Dielectric test voltage 500 V a.c.
Power dissipation Typ. 2.7 W
Current consumption +5 V Modulebus 50 mA
Current consumption +24 V Modulebus 0
Current consumption +24 V external 0
