The GDD360C 3BHE047217R0101 is an 8 channel 230 V a.c./d.c. relay (NO) output module for the S800 I/O. The maximum output voltage is 250 V a.c./d.c. and the maximum continuous output current is 3 A. All outputs are individually isolated. Each output channel consists of optical isolation barrier, output state indication LED, relay driver, relay and EMC protection components. The relay supply voltage supervision, derived from the 24 V distributed on the ModuleBus, gives an error signal if the voltage disappears, and the Warning LED turns on. The error signal can be read through the ModuleBus. This supervision can be enabled/disabled with a parameter.

GDD360C 3BHE047217R0101 ABB Industrial plc

GDD360C 3BHE047217R0101 ABB Industrial plc

Features and benefits

1.8 channels for 230 V a.c./d.c. relay Normal Open (NO) outputs

2.8 isolated channels

3.Output status indicators

4.OSP sets outputs to predetermined state upon error detection

GDD360C 3BHE047217R0101 ABB Industrial plc

GDD360C 3BHE047217R0101 ABB Industrial plc

Detailed data

Isolation    Individually isolated, channel-to-channel and to circuit common

Current limiting       Can be current limited by the MTU

Maximum field cable length        600 meters (656 yards)

Event recording accuracy                -0 ms / +1.3 ms

Rated insulation voltage    250 V

Dielectric test voltage           2000 V a.c.

Power dissipation            Typ. 2.9 W

Current consumption +5 V Modulebus                 60 mA

Current consumption +24 V Modulebus            140 mA

Current consumption +24 V external               0

GDD360C 3BHE047217R0101 ABB Industrial plc PDF

GDD360C 3BHE047217R0101

GDD360C 3BHE047217R0101 ABB Industrial plc

Environment and certification

CE mark            Yes

Electrical safety           EN 61010-1, UL 61010-1, EN 61010-2-201, UL 61010-2-201

Hazardous Location               –        Marine certificationABS, BV, DNV, LR

Temperature, Operating             0 to +55 °C (+32 to +131 °F), approvals are issued for +5 to +55 °C

Temperature, Storage         -40 to +70 °C (-40 to +158 °F)

Pollution degree       Degree 2, IEC 60664-1

Corrosion protection      ISA-S71.04: G3

Relative humidity         5 to 95 %, non-condensing

Max ambient temperature        55 °C (131 °F), for vertical mounting in compact MTU 40 °C (104 °F)

Protection class   IP20 according to IEC 60529

Mechanical operating conditions IEC/EN 61131-2

EMC          EN 61000-6-4, EN 61000-6-2

Overvoltage categories   IEC/EN 60664-1, EN 50178

Equipment class    Class I according to IEC 61140; (earth protected)

RoHS compliance     DIRECTIVE/2011/65/EN (EN 50581:2012)

WEEE compliance    DIRECTIVE/2012/19/EU
