Honeywell CC‑PWRR01 is a 1+1 redundant 24VDC power supply module designed for Honeywell C300 / ControlEdge PLC/DCS systems, delivering continuous, stable power to critical control components with automatic failover and high efficiency.
Brand & Model
Brand: Honeywell
Part Number: CC‑PWRR01 (Alternate P/N: 51199929‑100)
Type: 1+1 Redundant Power Supply Module
Associated Series: Honeywell C300 / ControlEdge PLC/DCS
Alternate P/N: 51199929‑100
Core Features
1+1 Redundancy: Dual independent power channels with seamless, bumpless automatic failover to ensure uninterrupted 24VDC output during single‑channel failure.
Dual Input Compatibility: Supports wide‑range AC or DC input for flexible installation in industrial sites.
High Efficiency: >90% typical efficiency reduces energy loss and heat generation.
Load Sharing: Balances current between redundant channels for optimal thermal performance.
Visual Diagnostics: LED indicators for input presence, output status, and fault alarms to enable quick troubleshooting.
Modular Design: Blade‑style construction for hot swapping and easy field replacement without system shutdown.
Industrial Safety: Complies with CE, UL, and hazardous location (HAZLOC) approvals for safe operation in harsh environments.
Overcurrent/Overvoltage Protection: Built‑in safeguards to protect connected control components from power anomalies.
Technical Specifications
Input Voltage: 85–264V AC (47–63 Hz), 120–370V DC
Output Voltage: 24V DC (nominal; typical regulation ±1%)
Output Current: 5A per channel; 10A total (20A variant available)
Power Efficiency: >90%
Operating Temperature: 0°C to 60°C
Storage Temperature: -40°C to 85°C
Humidity: 5%–95% RH (non‑condensing)
Dimensions: 125mm × 125mm × 105mm (typical)
Weight: ~2 kg
Protection Class: IP20 (chassis)
MTBF: >100,000 hours
