Honeywell CC-TCNT01 timer/counter module

Introduction
The Honeywell CC-TCNT01 is a high-performance timer/counter module engineered for seamless integration with Honeywell’s Experion PKS (Process Knowledge System) and ControlEdge control platforms, specifically designed to meet the precision timing and counting requirements of industrial automation and process control systems. As a core I/O component, this module delivers versatile functionality, supporting both timer operations (such as on-delay, off-delay, and pulse generation) and counter functions (including up-counting, down-counting, and bidirectional counting) to monitor and control critical industrial processes. It serves as a reliable interface between the central controller and field devices, enabling accurate measurement of event frequencies, process durations, and sequential operations—essential for applications like production line pacing, batch processing, and equipment cycle monitoring. The CC-TCNT01 features a robust modular design with built-in diagnostic capabilities, channel-level isolation, and hot-swappable functionality, ensuring minimal downtime during maintenance while withstanding the harsh electromagnetic interference and environmental conditions common in industrial settings. It is widely deployed across sectors including petrochemicals, power generation, manufacturing, and water treatment, where precise timing and counting are critical to operational efficiency, safety, and process integrity.

Technical Specifications
General Characteristics
The CC-TCNT01 is part of Honeywell’s Series C I/O module family, fully compatible with C300 controllers and Experion PKS distributed control systems (DCS). It supports redundant system configurations to enhance operational reliability and can be seamlessly integrated into existing control architectures without requiring extensive reconfiguration. The module adopts a compact, rack-mountable design optimized for dense I/O layouts, reducing control cabinet space requirements while facilitating easy installation and expansion.
Core Functionality & Channel Configuration
Equipped with 16 independent timer/counter channels, each configurable for either timer or counter operation via software, the module offers flexible adaptation to diverse application needs. Timer functions include on-delay (TON), off-delay (TOF), pulse-width modulation (PWM), and cyclic pulse generation, with adjustable time bases ranging from 1ms to 1s. Counter modes support up-counting, down-counting, and up/down counting with preset values, capable of handling both rising-edge and falling-edge trigger signals for precise event detection.

Signal Specifications
For counter operations, the module supports input signal voltages of 24VDC (sinking or sourcing) with a typical input current of 5mA, ensuring compatibility with standard industrial sensors and switches. The maximum counting frequency is 100kHz per channel, enabling high-speed event counting for fast-paced industrial processes, while the 32-bit counting resolution ensures accuracy even for long-duration or high-volume counting tasks. Timer operations offer a time range from 1ms to 999 hours, with a timing accuracy of ±0.1% of the set value, meeting the precision requirements of most industrial control scenarios.
Isolation & Anti-Interference
To ensure signal integrity and system protection in noisy industrial environments, the CC-TCNT01 incorporates galvanic isolation between channels and between the field side and logic side, with an isolation voltage rating of 2500VAC. This design effectively mitigates electromagnetic interference (EMI), radio frequency interference (RFI), and ground loop issues, preventing cross-talk between channels and safeguarding the central controller from voltage transients. Additionally, integrated signal filtering enhances noise immunity, ensuring stable operation even in harsh electrical environments.
Power Requirement
The module operates on a 24VDC backplane power supply, with a typical power consumption of 10W and a maximum current draw of 400mA under full load. The low-power design contributes to energy efficiency and reduces heat generation, supporting extended operational lifespans and compatibility with power-constrained systems. It also features overvoltage and reverse polarity protection to prevent damage from power supply anomalies.
Environmental Adaptability
Designed for industrial durability, the CC-TCNT01 operates within a temperature range of -40°C to 70°C, with a storage temperature range of -40°C to 85°C, making it suitable for both indoor and outdoor control cabinet installations. It accommodates relative humidity levels of 5% to 95% (non-condensing) and exhibits resistance to vibration (0.5g RMS, 5Hz-500Hz) and shock (5g, 20ms), ensuring reliable performance in demanding mechanical environments. The module’s enclosure meets IP20 protection standards, safeguarding internal components from dust and accidental contact.
Diagnostics & Maintenance
The CC-TCNT01 is equipped with comprehensive diagnostic capabilities, including channel-level fault detection (such as open-circuit and short-circuit detection for input signals) and module health monitoring. Front-panel LED indicators provide real-time status feedback for power, communication, and individual channel operation, enabling quick troubleshooting and reducing maintenance time. The hot-swappable design allows for module replacement without shutting down the entire control system, minimizing operational downtime and enhancing system availability.
