LG1093AA46 Honeywell Flame Sensor PLC
Functional Architecture
-
Triple-Channel Design
- 3 isolated input channels with independent signal processing chains
- Per-channel operations:
▸ Thermoelectric voltage acquisition
▸ Linearization & cold-junction compensation (CJC)
▸ 16-bit signed integer conversion (LSB = 0.125°C/°F)
-
Data Integrity Assurance
- Mid-value selection algorithm for cross-processor consensus
- Scan-synchronous value validation
LG1093AA46 Honeywell Flame Sensor PLC
LG1093AA46 Honeywell Flame Sensor PLC
Configuration & Diagnostics
| Feature | Isolated Module | Non-Isolated Module |
|---|---|---|
| Burnout Detection | Programmable via TriStation 1131 (upscale/downscale) | Field termination dependent |
| Fault Indication | Cold-junction LED | Unified Fault LED |
| Compensation | Triplicated CJC transducers | Triplicated CJC transducers |
Failure Modes Handling:
- Burnout condition → Outputs ±32,767 (full-scale saturation)
- Overrange input → Forces +32,767 output
LG1093AA46 Honeywell Flame Sensor PLC
LG1093AA46 Honeywell Flame Sensor PLC
Operational Enhancements
-
Self-Monitoring
- Automatic 5-second calibration cycle:
▸ Internal precision voltage reference validation
▸ Reference junction compensation update
- Automatic 5-second calibration cycle:
-
Fault Containment
- Channel-to-channel galvanic isolation (IEC 61000-4)
- Continuous per-channel diagnostic monitoring
-
Maintenance Features
- Hot-swappable design (online replacement capability)
- Mechanical keying system (prevents chassis misalignment)
- Remote termination via dedicated interface cable
LG1093AA46 Honeywell Flame Sensor PLC PDF
