Technical Specifications of Motorola MVME6100
Brand & Model: Motorola MVME6100 (VMEbus Single-Board Computer)
Product Type: Rugged embedded SBC, compliant with VME64x and IEEE 1014-1987 standards
Processor: PowerPC 750FX (G4 core) running at 800MHz or 1GHz (configurable), with 512KB L2 cache
Memory:
DDR SDRAM: Up to 2GB (dual-channel, 333MHz/400MHz), ECC error correction support
Flash Memory: 16MB (boot flash) + 512MB/1GB user flash (configurable)
Local SRAM: 64KB (non-volatile, battery-backed optional)
Storage Interfaces:
IDE/PATA interface (supports 2.5-inch hard disk drive or solid-state drive)
CompactFlash Type II slot (for removable storage expansion)
I/O Interfaces:
VME64x Interface: 32-bit/64-bit data bus, 33MHz/66MHz bus speed, dual VMEbus masters
Ethernet: 2 x 10/100/1000Mbps Gigabit Ethernet ports (RJ45, TCP/IP compliant)
Serial Ports: 2 x RS-232/RS-422/RS-485 configurable UARTs (DB9 connectors)
USB: 2 x USB 2.0 ports (host mode, Type A connectors)
Digital I/O: 8-channel programmable digital input/output (isolated)
Other Interfaces: PCI Mezzanine Card (PMC) slot (for I/O expansion), JTAG debug port
Power Supply:
Input Voltage: +5V DC ±5%, +12V DC ±10%, -12V DC ±10% (VMEbus standard power)
Power Consumption: Typical 25W (at 800MHz processor), max 35W (full load)
Temperature Ratings:
Operating Temperature: -40°C to +85°C (-40°F to +185°F) (extended temperature range)
Storage Temperature: -55°C to +125°C (-67°F to +257°F)
Environmental Resistance:
Humidity: 5%~95% RH (non-condensing, operating temperature ≤60°C)
Vibration Resistance: 10g (10Hz~2000Hz, random vibration, MIL-STD-810F)
Shock Resistance: 50g (11ms duration, half-sine wave, MIL-STD-810F)
Altitude: ≤12,000m (39,370ft)
Protection Rating: IP20 (board-level protection, dust-resistant for rack-mounted use)
Mounting Type: VMEbus chassis mounting (3U VME form factor)
Dimensions (W×H×D): 160mm × 100mm × 25mm (6.30in × 3.94in × 0.98in) (3U VME standard size)
Weight: Approx. 450g (0.99lb)
