NINT-72C ABB

Hardware Installation‌

1. ‌Pre-Safety Checks‌

   • De-energize the host system and verify 0V at terminals using a certified multimeter.
   • Use ESD wrist strap bonded to the S800 rack’s grounding point (ESD protection ≥1MΩ).

2. ‌Module Insertion‌

   • Align module grooves with S800 rack guides (slots 4–15 compatible).
   • Insert at 30° angle until backplane connector seats, then rotate downward until latch snaps.
   • Secure with top/bottom M4 screws (torque: 0.8 N·m ±10%).

3. ‌Compact-Specific Steps‌

   Applies to NINT-72C only:

   • Engage DIN rail clips (for auxiliary mounting): Push module onto 35mm rail until “click”.
   • Validate clearance: ≥50mm above/below module for ventilation.



Wiring & Power‌

1. ‌Signal Terminals (X1)‌

   ‌Terminal‌	‌Function‌	‌Specifications‌
   ‌AI1–AI8‌	Analog Inputs	±10V / 0–20mA, 16-bit res.
   ‌COM‌	Common Reference	Galvanically isolated
   ‌SHLD‌	Shield Drain	Bond to chassis ground

   • Use twisted-pair shielded cables (max length 100m).

2. ‌Power Connections‌

   • ‌Primary PSU‌: Supply 24VDC ±5% to ‌TB2‌ (pins 1+: 24V, 2–: 0V).
   • ‌Redundant PSU‌ (optional): Connect backup to ‌TB2‌ (pins 3+: 24V, 4–: 0V).

 ‌Status Indicators‌

️ ‌Critical Warnings‌

• ‌DO NOT HOT-SWAP‌: Power cycle required for module replacement.
• ‌ISOLATION CHECK‌: Verify 500VDC isolation between channels before energizing.
• ‌AMBIENT‌: Operate at –40°C to +70°C; derate above 55°C per IEC 61131-2.

 ‌Software Configuration‌

1. ‌Address Setting‌

   • Set rotary switches (SW1-SW2) for logical address:
     textCopy Code
     SW1 (MSB) | SW2 (LSB) → Address range: 0–15


2. ‌Automation Builder Setup‌

   textCopy Code
   Project Navigator → Hardware Configuration → S800 I/O →
Drag "NINT-72C" to target slot → Assign module properties:
• Input Type: Voltage/Current
• Filter: 50/60Hz noise rejection
• Alarms: Configurable thresholds


3. ‌Calibration‌

   • Access calibration mode via service port (requires ABB CAL-72 tool).

NINT-72C ABB pdf
