NTAI05 Module Parameters
General Specifications
- Module Type: 8-channel isolated analog input
- Compatibility: ABB S800 I/O system (slots 4–15)
- Isolation: 500V channel-to-channel & channel-to-backplane
Electrical Characteristics
| Parameter | Value |
|---|---|
| Input Type | Voltage: ±10V, Current: 0–20mA |
| Resolution | 16-bit (incl. sign bit) |
| Accuracy | ±0.1% of span (25°C) |
| Sampling Rate | 10 ms/channel (all channels) |
| Common-Mode Rejection | >120 dB at 50/60 Hz |
Environmental Ratings
- Operating Temp.: –25°C to +70°C (derate linearly above 55°C)
- Humidity: 5–95% non-condensing
- Vibration: 5–500 Hz, 1g amplitude (IEC 60068-2-6)
Certifications
- Safety: UL 508, EN 61131-2
- EMC: EN 61326-1 (Industrial Immunity)
NTAI05 ABB pdf
NTAI05
♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦
