POW-01C ABB APOW-01C POWER SUPPLY BRD

Operation guide for ABB POW-01C Power Quality Analyzer‌

Safety Precautions‌

1. ‌Pre-Operation Checks‌
   • Verify input voltage range (50-480V AC/DC) matches circuit under test.
   • Ensure CAT IV 600V-rated test leads are undamaged.
   • Ground the device via PE terminal (torque: 2.3 N·m).

Hardware Setup‌

1. ‌Connection Diagram‌

   textCopy Code
   Phase Wires:
L1 → RED channel (V1+/I1)
L2 → YELLOW channel (V2+/I2)
L3 → BLUE channel (V3+/I3)
Neutral → BLACK terminal (Vn)

   • ‌CT Installation‌: Clip Rogowski coils with arrow pointing toward load.

2. ‌Display Initialization‌

   • Press PWR for 3 seconds → Wait for self-test completion (LEDs cycle green).
   • Confirm battery level >80% (low-battery icon requires immediate charging).

Measurement Procedure‌

‌Basic Operation‌

1. ‌Parameter Monitoring‌

   textCopy Code
   Navigation:
HOME → Voltage/Current → Select L1/L2/L3/Σ
HOME → Power → View kW/kVAR/PF
HOME → Harmonics → THDv / THDi tabs

   • ‌Snapshot‌: Press FREEZE to capture transient values

2. ‌Waveform Capture‌

   textCopy Code
   Steps:
1. MENU → Recorder → Set duration (1s-30d)


2. Trigger on: Voltage sag/swell (EN 50160 limits)


3. Export via USB: .CSV or .PQDIF format


 ‌Advanced Functions‌

1. ‌Alarm Configuration‌

   textCopy Code
   Path: MENU → Alarms →
• Set thresholds: Voltage ±10%, Frequency ±0.5Hz
• Assign relays: K1/K2 for audible/visual alerts


2. ‌Energy Billing Verification‌

   • Enable tariff registers: SETUP → Energy → TOU Tables
   • Validate against IEC 62053-21 Class 0.5S

POW-01C ABB  pdf

64605666

♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦
