PP836 ABB Panel 800 portfolio NEW
The USB Type A connector on PP836 is connected to a USB Host port on a PC. Crossover Ethernet patch cable (twisted pair cable) with RJ45 connectors is connected between the Ethernet RJ45 port on CB810 and the Ethernet PP836 port on the Panel 800.Follow the instructions in the manual for the operator panel to make settings for the Ethernet / TCP/IP project transfer in the configuration tool.For information about the cables to be used when connecting the operator panel to the controller, please refer to the help file for the driver in question.
PP836 ABB Panel 800 portfolio NEW
PP836 ABB Panel 800 portfolio NEW
Technical Specifications
• Single chip USB to 10/100 Mbps Fast Ethernet.
• Compliant with USB specifications 1.0, 1.1, and 2.0.
• Full/High Speed USB Device with bus power capabilities.
• IEEE 802.3u 100BASE-T, TX, and T4 compatible.
• Embedded 7K*16 bit SRAM, 256*16 bit SRAM and 8 FIFOs.
• Supports both full-duplex or half-duplex operation Fast Ethernet.
• Supports suspended mode and remote wake up.
• Optional PHY power down mode for power savings.
• Supports automatic loading of Ethernet ID, USB Descriptors and Adapter
Configuration from EEPROM on power-on initialization.
• Ethernet PHY loop-back diagnostic capability.
PP836 ABB Panel 800 portfolio NEW
PP836 ABB Panel 800 portfolio NEW
Other Connections and Peripherals
Cables, peripheral equipment and accessories must be suitable for the application and its environment. For further details or recommendations, please refer to the supplier.CB810 is not approved for fixed installation or for use when the Panel 800 is
installed and/or running. It should only be used for project/file transfer between a PC and the Panel 800.PP836 cannot be connected directly to the Panel 800.When using a compact flash card, do not remove the card when the busy indicator is illuminated.
PP836 ABB Panel 800 portfolio NEW PDF
PP836 ABB Panel 800 portfolio NEW
♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦
Shipping:
1. Your item will be shipped to all countries via EMS, unless one country cannot be shipped via EMS. We will choose DHL, UPS, or FedEx. Please leave us your phone number.
2. We will ship the product to you on the same day or within 1-2 working days after receiving your payment. The shipping time depends on the country/region where you reside, the customs and habits of your country/region, and especially during peak hours.
3. Assuming (assuming) that the item requires payment of tariffs from your country, the buyer is obligated. We are not responsible for any taxes or customs fees in your country/region.
Return Policy:
1. Please contact us before returning the item.
2. The buyer should inform the seller of all returned items within 7 days after receiving the package. We reserve the right to reject any request to inform the seller for more than 7 days.
3. Returned products must have all original packaging and be in good condition.
Response policy:
If you are satisfied with the purchase, please leave us an active response.
2. If you have any questions about the outcome of the transaction or product, please contact us first and we will do our best to satisfy you!
3. Please do not reply with negative feedback before contacting us!
