PP845A 3BSE042235R2 ABB Operator Panel
The USB Type A connector on PP845A 3BSE042235R2 is connected to a USB Host port on a PC. Crossover Ethernet patch cable (twisted pair cable) with RJ45 connectors is connected between the Ethernet RJ45 port on CB810 and the Ethernet PP845A 3BSE042235R2 port on the Panel 800.Follow the instructions in the manual for the operator panel to make settings for the Ethernet / TCP/IP project transfer in the configuration tool.For information about the cables to be used when connecting the operator panel to the controller, please refer to the help file for the driver in question.
PP845A 3BSE042235R2 ABB Operator Panel
PP845A 3BSE042235R2 ABB Operator Panel
Technical Specifications
• Single chip USB to 10/100 Mbps Fast Ethernet.
• Compliant with USB specifications 1.0, 1.1, and 2.0.
• Full/High Speed USB Device with bus power capabilities.
• IEEE 802.3u 100BASE-T, TX, and T4 compatible.
• Embedded 7K*16 bit SRAM, 256*16 bit SRAM and 8 FIFOs.
• Supports both full-duplex or half-duplex operation Fast Ethernet.
• Supports suspended mode and remote wake up.
• Optional PHY power down mode for power savings.
• Supports automatic loading of Ethernet ID, USB Descriptors and Adapter
Configuration from EEPROM on power-on initialization.
• Ethernet PHY loop-back diagnostic capability.
PP845A 3BSE042235R2 ABB Operator Panel
PP845A 3BSE042235R2 ABB Operator Panel
Other Connections and Peripherals
Cables, peripheral equipment and accessories must be suitable for the application and its environment. For further details or recommendations, please refer to the supplier.CB810 is not approved for fixed installation or for use when the Panel 800 is
installed and/or running. It should only be used for project/file transfer between a PC and the Panel 800.PP845A 3BSE042235R2 cannot be connected directly to the Panel 800.When using a compact flash card, do not remove the card when the busy indicator is illuminated.
PP845A 3BSE042235R2 ABB Operator Panel PDF
PP845A 3BSE042235R2 ABB Operator Panel
♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦
