PP875 ABB touch screen HMI NEW IN STOCK

ABB PP875: Introduction & Technical Specifications
Introduction
The ABB PP875 (Model No. 3BSE092977R1) is a 7-inch resistive touch screen HMI from the Panel 800 Series, engineered for intuitive operator control and monitoring in industrial automation environments like manufacturing, process control, and energy sectors. It features a high-brightness 800×480 TFT/LED display, an ARM9 1 GHz processor, and multi-protocol connectivity, seamlessly integrating with ABB System 800xA and third-party controllers via Ethernet, serial ports, and USB. Key advantages include front IP66/NEMA 4X protection for harsh on-site conditions, low power consumption, and support for Panel Builder 800 configuration software, enabling rapid application development with pre-built templates and libraries for efficient process visualization and control800xahardwareselector.automation.abb.com. It offers reliable 24/7 operation, real-time data handling, and flexible mounting options (panel/VESA), making it ideal for space-constrained industrial settings requiring robust HMI performance.
Technical Specifications
Basic Information
Model: PP875 (3BSE092977R1)
Manufacturer: ABB
Series: Panel 800
Product Type: 7-inch Resistive Touchscreen HMI
Configuration Software: Panel Builder 800
Display Type: 7-inch Widescreen TFT/LED (16:9)

Touch Technology: Resistive Touch
Performance & Memory
Processor: ARM9 (1 GHz)
Main Memory: 512 MB DDR RAM
Storage: 2 GB SSD (1.5 GB available for applications)
Brightness: 350 cd/m²
Resolution: 800 × 480 Pixels
Real-Time Clock: Integrated with Backup Battery
Dimming: Adjustable Display Dimming
Connectivity
Ethernet: 1×10/100 Base-T (Shielded RJ45)
Serial Ports: 1×RS-232, 1×RS-422/485 (COM2 configurable as RS485)
USB: 1×USB 2.0 (500 mA)
Supported Protocols: Modbus, COMLI, PROFIBUS DP, Ethernet/IP (varies by driver)
Power & Environmental
Power Supply: +24 V DC (18-32 V DC)
Power Consumption: 14.4 W

Operating Temperature: -10°C to +60°C
Storage Temperature: -40°C to +80°C
Humidity: 5-95% RH (Non-Condensing)
Protection Class: Front IP66/NEMA 4X/12; Rear IP20
Physical & Mounting
Dimensions (W×H×D): 204 mm × 143 mm × 50 mm
Cut-Out Size: 187 mm × 126 mm
Mounting Depth: 43 mm (143 mm including clearance)
Mounting Options: 19-inch Panel Mount, VESA 75×75
Net Weight: 0.8 kg
Frame Material: White Powder-Coated Aluminum
