Parameter configuration guide for the ABB PPC902AE101 controller
Core Parameter Settings
System Identification
Menu Path: MAIN MENU → System → Device Info
• Device Name: [Max 16 ASCII chars]
• Location Tag: (e.g., "MX-PLC-02")
• Time Zone: UTC+8:00 (ISO 8601 format)
Communcation Protocols
| Protocol | Parameter Path | Default Settings |
|---|---|---|
| Modbus TCP | Comm → Ethernet → MBAP |
Port 502, Unit ID=1, Timeout=3000ms |
| PROFIBUS DP | Fieldbus → PROFIBUS → Slave |
Address=126, Baud Rate=12Mbps |
| BACnet/IP | Building Automation → BACnet |
Device ID=1001, BVLL Port=47808 |
Process Control Parameters
Analog I/O Configuration
Menu: I/O → Analog Inputs → AI1
• Signal Type: 4-20mA (selectable: 0-10V, RTD Pt100)
• Scaling:
Low Limit: 4mA = 0.0 bar
High Limit: 20mA = 25.0 bar
• Filtering: 50Hz rejection enabled
PID Loop Tuning (Example)
Path: Control → PID Blocks → Loop1
• PV Source: AI2
• Setpoint: 75.0°C (Remote via MODBUS)
• Tuning:
Kp=1.25, Ti=8.5s, Td=1.2s
Anti-Windup: 10% clamp
• Output: AO1 (0-100% = 4-20mA)
HMI & Visualization
Display Parameters
Navigation: HMI → Display Settings
• Brightness: 70% (0-100% adjustable)
• Screen Timeout: 10 minutes (off when inactive)
• Language: English (supports 8 languages)
Alarm Management
Path: Alarms → Configuration
• Priority Levels: 4 (Critical/High/Medium/Low)
• Hysteresis:
Temp High Alarm: Setpoint=85°C, Hyst.=2.5°C
Pressure Low: Setpoint=1.5bar, Hyst.=0.2bar
• Latching Mode: Enabled for Critical alarms
Network Security
Firewall & Access Control
Menu: Security → Firewall
• IP Filtering:
Allow: 192.168.1.0/24
Deny: All external
• Password Policy:
Min. length: 8 chars
Complexity: Upper+lower+digit required
Session Timeout: 15 min
User Permissions
| Role | Access Level |
|---|---|
| Administrator | Full configuration rights |
| Maintenance | Alarm acknowledge + manual override |
| Operator | View-only + setpoint adjustment |
Energy Management
Power Optimization
Path: Energy → Tariff Settings
• Time-of-Use Schedule:
Peak: 08:00-20:00 @ $0.25/kWh
Off-Peak: 20:00-08:00 @ $0.12/kWh
• Load Shedding:
Threshold: 150kW → Disable non-critical loads
Data Logging
Configuration: Data → Historian
• Sampling Rate:
Fast data: 100ms (for transients)
Slow data: 1 min (trending)
• Storage:
Internal: 64MB (circular buffer)
External: FTP to NAS (max 1GB/day)
• Triggers: Start on alarm OR manual command♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦
