Rexroth KSM02.1B-041C-42N-M1-HG2-ET-L3-D7-NN-FW servo drive

Rexroth KSM02.1B-041C-42N-M1-HG2-ET-L3-D7-NN-FW: Introduction & Technical Specifications
Introduction
The Rexroth KSM02.1B-041C-42N-M1-HG2-ET-L3-D7-NN-FW (part number R911334434) is a motor-integrated servo drive from Bosch Rexroth’s IndraDrive Mi KSM series, integrating a synchronous servo motor, inverter, control electronics, and firmware into a single compact housingRexroth. It uses a hybrid cable for DC power and Multi-Ethernet communication, with natural convection cooling via the motor housing surfaceRexroth. Key features include Multi-Ethernet connectivity, absolute optical encoder feedback, Safe Torque Off (STO) safety function, IP65 protection, and a plain shaft with seal; it is ideal for precision motion control in packaging, material handling, and general automation, offering easy installation, reduced wiring, and reliable performance in harsh industrial environments.
Technical Specifications
Basic Information
Model: KSM02.1B-041C-42N-M1-HG2-ET-L3-D7-NN-FW
Manufacturer: Bosch Rexroth
Part Number: R911334434
Product Type: Motor-Integrated Servo Drive (IndraDrive Mi KSM Series)
Performance Level: Basic
Design Version: 1

Motor & Drive Performance
Nominal Power: 0.47 kW (470 W)
Continuous Torque (25°C): 2.2 Nm
Peak Torque: 9.4 Nm
Torque Constant (20°C): 1.60 Nm/A
Voltage Constant (20°C): 98.2 V/1000 min⁻¹
Max Speed: 5500 rpm
Max Current: 6.8 A
Winding Code: 42Rexroth
Power & Communication
Supply Voltage: DC 750 V (600-800 V DC operating range)
Control Voltage: 30-42 V DC (29.5 W typical consumption)
Communication: Multi-Ethernet (2 x M12 ports; PROFINET, EtherNet/IP, EtherCAT)
Connector: Hybrid connector (power + communication)
Encoder & Safety
Encoder: Absolute optical (Hiperface DSL, single-turn; 128 signal periods/rev)
Safety Function: Safe Torque Off (STO), SIL 2, PL d compliant
Brake: No holding brake
Mechanical & Environmental
Motor Size/Length: 041/C
Cooling: Natural convection (self-cooling)
Shaft: Plain shaft with shaft seal
Protection Class: IP65 (per IEC 60529)
Operating Temperature: 0-40°C (non-condensing)
Weight: 5.6 kg
Certifications: CE, UL, ATEX, IECEx compliantRexroth
Additional Features
Diagnostics: Comprehensive self-diagnostics, status monitoring
Mounting: Flange mounting, compatible with standard industrial interfaces
Cable: Hybrid cable for DC power and communication
Sealing: Shaft sealing ring for contamination protection
