SDCS-MEM-8 3adt200007r0101 ABB Memory Card

SDCS-MEM-8 3adt200007r0101 ABB Memory Card

DCS800-R Upgrade Kits
Conditions caused by the application
 In case of an additional application three scenarios are possible
 Application program located in the APC1 or APC2 of a DCV 700.
 APC1: No interface available
 APC2: Optical connection board YPQ112 is to add between APC2 and SDCS-COM81 and control logic is to modify
 The application program is as function blocks in the DCS 500 or DCS 500B.                                                                                                                                                                                             DriveAP Programmimg or CoDeSys Programming
 The application program is located in the AMC board of a DCS 600 see APPLIC NAME(4.03)                                                                                                                                                                               CoDeSys Programming
 Master-follower configurations
 Master-follower via SDCS-COM-8 should be used for upgrading a DCS 600. The fiber optic cable can be reused.
 Master-follower via DCSLink should be used for upgrading a DCS 500 or DCS 500B.
 Hard-Parallel configuration
 Additional engineering is needed. Please contact your local ABB .

SDCS-MEM-8 3adt200007r0101 ABB Memory Card

SDCS-MEM-8 3adt200007r0101 ABB Memory Card

Installation of the PE1354B fieldbus converter requires small modifications in the overriding control systeme.g. MP200. Furthermore the removal of the APC controller requires adaption of the existing APC software program either into the overriding system or into the drive via DriveAP or CoDeSys. Availability of the right software tools and programming skills are to ensure.                                                                                                                             Manual with detailed information
 For further information regarding hardware, assembling and commissioning see Manual 3ADW00256R0101
 Parameter settings
 After upgrading parameters have to be adjusted due to different parameter groups in DCS500/DCS600 and DCS800.
 For parameter comparison see document 3ADW000405R0201

SDCS-MEM-8 3adt200007r0101 ABB Memory Card

SDCS-MEM-8 3adt200007r0101 ABB Memory Card

For the communication with overriding control system additional interface devices are toimplement.
See next slides
SDCS-CON-1 board is to replace by SDCS-CON-4 including SDCS-COM-81,SDCS-DSL-4 and panel                                                                                                                                                            In case of frame size C3 the existing SDCS-PIN51 is to be replaced by a new SDCS-PIN-51

Not supported parts
 all old field exciters for DCS 500, DCS 500B and DCS 600,
 DCS-IOE-1
 control panels CDP 310 and CDP 311
 Nxxx fieldbus adapter used with DCS 500
 APC1 used for DCV 700
 Reuse of APC2 requires modifications in the control logic and additional hardware
 All old tools like DDCTool, CMTTool,DriveWindow 1.x and DriveWindow 2.1

SDCS-MEM-8 3adt200007r0101 ABB Memory Card

♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦

Shipping:
1. Your item will be shipped to all countries via EMS, unless one country cannot be shipped via EMS. We will choose DHL, UPS, or FedEx. Please leave us your phone number.
2. We will ship the product to you on the same day or within 1-2 working days after receiving your payment. The shipping time depends on the country/region where you reside, the customs and habits of your country/region, and especially during peak hours.
3. Assuming (assuming) that the item requires payment of tariffs from your country, the buyer is obligated. We are not responsible for any taxes or customs fees in your country/region.

Return Policy:
1. Please contact us before returning the item.
2. The buyer should inform the seller of all returned items within 7 days after receiving the package. We reserve the right to reject any request to inform the seller for more than 7 days.
3. Returned products must have all original packaging and be in good condition.

Response policy:
If you are satisfied with the purchase, please leave us an active response.
2. If you have any questions about the outcome of the transaction or product, please contact us first and we will do our best to satisfy you!
3. Please do not reply with negative feedback before contacting us!
