ABB 3BHE034863R0001 High-Voltage Inverter Module Technical Specifications
Core Identification
- Manufacturer: ABB (Power & Automation Technologies)
- Model: UDC920BE01 1
- Order Code: 3BHE034863R0001 1
- Series: Likely belongs to ACS 1000/5000 HV drive family (requires verification)
Electrical Parameters
| Category | Specification |
|---|---|
| Input Voltage | 3kV/6kV/10kV AC (configurable per application) 1 |
| Output Control | Variable frequency drive (VFD) for AC motors |
| Harmonic Distortion | <5% THD with built-in filters 1 |
| Efficiency | ≥98% at full load 1 |
Functional Features
- Motor Control:
- Soft start/stop with torque limiting 1
- Multi-pump/multi-master synchronization 1
- Protection:
- Overcurrent/overvoltage/ground fault protection 1
- IGBT temperature monitoring 1
Mechanical & Environmental
- Enclosure: IP20 standard (optional IP54 for harsh environments) 1
- Cooling: Forced air cooling (ducting recommendations apply) 1
- Ambient Temperature: 0°C to +55°C operational 1
Communication & Integration
- Fieldbus Options:
- PROFIBUS DP
- Modbus RTU/TCP 1
- DCS Compatibility:
- Interfaces with ABB 800xA/Symphony Plus systems
♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦♦…♦
