XV-303-15-C00-A00-1B EATON touch panel

Eaton XV‑303‑15‑C00‑A00‑1B Product Overview & Technical Specifications
Product Brief
The Eaton XV‑303‑15‑C00‑A00‑1B is a high‑performance 15.6‑inch advanced HMI operator panel with capacitive multi‑touch, dual Ethernet, and rich industrial communication interfaces, designed for reliable machine control and visualization in harsh industrial environments.
Brand  Eaton
Model  XV‑303‑15‑C00‑A00‑1B (XV300 series)
Dimensions
The panel has physical dimensions of 403.7 mm (depth) × 254.9 mm (width) × 76.6 mm (height) and a weight of approximately 3.9 kg (8.6 lbs), with a 15.6‑inch widescreen display (1366 × 768 resolution) and a rugged front face for panel mounting.
Key Features
Capacitive Multi‑Touch (PCT): Responsive projected capacitive touch with anti‑reflective, toughened glass for durable operation in industrial settings.
High‑Performance Hardware: Powered by an 800 MHz ARM Cortex‑A9 processor with 512 MB RAM, 1 GB internal flash memory, and 128 KB retain memory for PLC‑related data retention.
Fanless Passive Cooling: Natural convection cooling ensures silent, reliable operation with no moving parts, supporting an operating temperature range of 0°C to +50°C and storage from −20°C to +60°C.
Dual Ethernet Segregation: Two independent 10/100 Ethernet ports enable secure separation of control and field‑level networks for enhanced system safety.

Flexible Visualization: Supports both landscape and portrait orientations, with integrated runtime software and web‑based visualization for remote monitoring and control.
Expandable Memory: SD card slot for external storage, system updates, and extended data logging, compatible with SDSC and SDHC cards.
Industrial Certifications: Compliant with EN 61000‑6‑4, EN 50178, and RoHS, suitable for demanding automation environments.
Input & Output
Input Specifications
Power Input: 24 V DC nominal (19.2 V to 30 V DC range), with typical power consumption of ~15 W and maximum 19.2 W.
Touch Input: Capacitive multi‑touch (PCT) for intuitive user interaction with the 15.6‑inch LED‑backlit TFT display (400 cd/m² brightness, 500:1 contrast ratio).
Communication Inputs: Dual 10/100 Ethernet ports, 1 × RS‑232, 1 × RS‑485, 1 × CAN, and USB Device for configuration, programming, and data exchange with PLCs and supervisory systems.
Memory Input: SD card slot for loading projects, updates, or extended data logging.
Output Specifications
Display Output: 15.6‑inch widescreen TFT with 1366 × 768 resolution, LED backlighting (software‑dimmable), and wide viewing angles (85°/85°/80°/80°) for clear visibility in industrial environments.
Communication Outputs: Dual Ethernet, RS‑232, RS‑485, CAN, and USB Host for connecting to field devices, HMIs, and SCADA systems, supporting standard industrial protocols.
Status Indicators: Integrated LEDs for power, network activity, and fault diagnostics to enable quick system troubleshooting.
Control Outputs: Supports integrated PLC functions (optional) with retain memory for reliable control signal generation to actuators and field devices.
