ABB XVC770AE 3BHE006414R0001 Product Profile & Technical Specifications
One-sentence Overview
ABB XVC770AE 3BHE006414R0001 is a high-voltage divider board (HVD Board Coated) designed for industrial automation and power control systems, featuring a compact form factor (178 x 305 x 59 mm), lightweight design (0.76 kg), robust construction with protective coating, and compatibility with ABB’s control systems, ensuring reliable voltage measurement and signal conditioning in harsh industrial environments.
1. Basic Product Information
Brand/Manufacturer: ABB Ltd., a global leader in power grid, industrial automation and electrical equipment solutions
Model Number: XVC770AE (also referred to as XV C770 AE)
Part Number: 3BHE006414R0001
Product Series: ABB XV C770 Series High-Voltage Divider Boards
Product Type: Industrial-grade high-voltage divider board with protective coating, dedicated to voltage measurement and signal conditioning in power control systems
Core Application: Voltage monitoring in industrial automation systems, power distribution networks, and control panels; signal conditioning for high-voltage inputs in ABB’s control systems and DCS; protection and measurement applications in medium and high-voltage power systems
Compliance & Certification: Complies with IEC 61010, IEC 60870-5 and IEC 61850 international standards; certified with CE, UL, and RoHS for global industrial application
Compatibility: Seamlessly integrates with ABB’s AC500 controllers, 800xA DCS, and other industrial control systems; compatible with standard industrial communication protocols
Product Status: Brand-new original industrial component, factory-sealed with complete technical documentation and installation instructions
Warranty: 1-year standard factory warranty (extended warranty options available through authorized distributors)
2. Physical Specifications
Weight: Net weight approximately 0.76 kg (760 g); gross weight including anti-static packaging approximately 1.0–1.2 kg
Dimensions (L × W × H): Standard board dimensions 178 mm × 305 mm × 59 mm (7.0 in × 12.0 in × 2.3 in), optimized for integration into ABB control cabinets and industrial panels
Mounting Method: Panel mounting via dedicated brackets; designed for secure installation in standard electrical enclosures and control cabinets
Housing Material: High-strength industrial-grade printed circuit board (PCB) with protective coating for enhanced durability and resistance to environmental factors; metal mounting points for stable mechanical retention
Protection Grade: IP20 (designed for indoor control cabinet installation, providing dust protection and preventing accidental contact with internal live parts)
Structural Features: Gold-plated contact points for reliable electrical connections; clearly marked terminals for easy identification and wiring; integrated mounting holes for secure installation; anti-static ESD protection design for all external interfaces; compact form factor optimized for space-saving in control cabinets
3. Electrical & Technical Parameters
Voltage Input: High-voltage input range (specific values depend on application, typically up to 1000 V AC/DC)
Voltage Output: Low-voltage output signal (typically 0–10 V DC or 4–20 mA) for measurement and control systems
Accuracy: High measurement accuracy of ±0.1% full scale (FS) for precise voltage monitoring
Frequency Response: Wide frequency range from DC to 100 kHz, ensuring accurate measurement of both AC and DC voltages
Isolation Performance: Electrical isolation between input and output channels; isolation voltage 2 kV AC (rms) for 1 minute without breakdown or flashover, compliant with IEC 60255 isolation safety standards
Power Consumption: Low power consumption of ≤ 2 W, suitable for long-term continuous operation in control systems
Input Impedance: High input impedance of ≥ 1 MΩ to minimize loading effect on measured circuits
Output Impedance: Low output impedance of ≤ 100 Ω for optimal signal transmission to measurement and control devices
4. Environmental Parameters
Operating Temperature Range: -20°C to +60°C (-4°F to +140°F), suitable for operation in most industrial environments
Storage Temperature Range: -40°C to +85°C (-40°F to +185°F) (non-condensing), allowing for long-term storage without performance degradation
Relative Humidity: 5% to 95% RH (non-condensing), compliant with IEC 60068-2-30 standards for humidity resistance
Vibration Resistance: Complies with IEC 60068-2-6; 5–150 Hz sinusoidal vibration with 0.5 g acceleration, ensuring reliable operation in industrial environments with mechanical vibration
Shock Resistance: Complies with IEC 60068-2-27; 15 g peak acceleration with 11 ms half-sine shock, capable of withstanding transportation and installation shocks
EMC Performance: Immunity to electromagnetic interference (EMI) and radio frequency interference (RFI) in industrial environments; meets IEC 61000-4 series standards for EMC immunity
Altitude Rating: Up to 2000 meters (6562 ft) at standard operating temperature; derating required for operation above 2000 meters to maintain thermal performance
