1TGE120011R1400 ABB

ABB 1TGE120011R1400
Brand: ABB
Model: 1TGE120011R1400
Product Name: Motor & Feeder Control Unit for MNS System
Country of Origin: Germany
HS Code Reference: 8538900090 (Intelligent low-voltage control module for MCC cabinet; final classification subject to official customs verification)
Technical Parameters
Overall dimension: 260 mm (Height) × 125 mm (Width) × 53 mm (Depth)
Net weight: 0.55 kg

Auxiliary power supply: 24 V DC, allowable voltage range 18 V DC to 32 V DC
Operating ambient temperature: -20 ℃ to +60 ℃
Storage temperature range: -40 ℃ to +85 ℃
Relative humidity: 5% to 95 %, non-condensing
Digital inputs: Multi-channel binary inputs for circuit breaker status feedback
Output channels: Relay outputs for contactor control and alarm signal triggering
Measuring functions: Real-time acquisition of three-phase current, voltage and power parameters
Protection functions: Thermal overload protection, phase loss protection, current unbalance protection, locked rotor protection and short-circuit alarm
Communication interface: Fieldbus interface compatible with MLink system protocols
Mounting method: Built-in installation inside MNS drawer unit
Housing material: Flame-retardant engineering plastic
Compliance standards: IEC 61850, IEC 60947 series low-voltage apparatus standards
Core functions: Motor start-stop logic control, electrical parameter measurement, multi-condition protection, operating data recording, fault event storage, remote parameter configuration and bidirectional data communication with automation host system
