B&R 3CP380.60-1 DCS CPU Module

B&R 3CP380.60-1 Product Description & Technical Specifications
Brand B&R (Bernecker + Rainer)
Model 3CP380.60-1
Order Part Number 3CP380.60-1
Product Name SYSTEM 2005 CPU Module
Place of Origin Austria
Customs HS Code 8537109060
Weight Approx. 0.5 kg (1.1 lbs) net
Operating Temperature -20°C to +55°C (-4°F to +131°F)
Storage Temperature -20°C to +60°C (-4°F to +140°F)
Humidity 0–95% non-condensing
Input Voltage 5 V DC

Input Current
Max 13 W total (without memory card or interface module)
Power Consumption Max 13 W (5 V DC, typical operation)
Processor Pentium III 500 MHz; typical instruction cycle time 0.012 µs
Memory
64 MB DRAM; 512 KB L2 cache;
CompactFlash slot (32 MB–512 MB support, memory card sold separately)
Communication Interfaces
– 1× USB 1.1 (bottom-mounted, not for programming)
– 1× RS232 (115.2 kBaud max, 15 m max distance, 9-pin DSUB)
– 1× 10/100 BASE-T Ethernet (RJ45, 100 m max distance)
– 1× aPCI slot (for interface modules like PROFIBUS, CAN, Ethernet Powerlink)

Key Features & Characteristics
1.High-integrity CPU for SYSTEM 2005, supporting fast cycle times and large data processing
2.Replaceable CompactFlash for flexible program storage and upgrades
3.Rich connectivity: USB, RS232, Ethernet, and expandable aPCI slot
4.Nonvolatile data buffering via lithium battery (3 V / 950 mAh, 4-year lifespan)
5.Status LEDs for READY, RUN, ERROR, SERVICE, battery, and CompactFlash status
6.Natural air cooling; IP20 protection rating for industrial installation
7.Compliant with C-UL-US, CE, and EMC standards for global market approval
8.Compatible with B&R Automation Studio for programming, diagnostics, and system configuration
Applications
Machinery control, process automation, high-speed data acquisition, modular machine tools, packaging lines, and industrial automation systems requiring robust, scalable CPU performance .
