ABB 3HAC024519-001/03 Product Introduction & Technical Specifications
Brand ABB
Model 3HAC024519-001/03
Order Number 3HAC024519-001/03
Product Name Rotary AC Servo Motor
Place of Origin Sweden
Customs Code HS Code 85371090 (for industrial automation servo motors & robotic drive components)
Dimensions Approx. 180mm × 120mm × 110mm (W×H×D)
Weight Net weight: 22.93 kg; Gross weight: 23.65 kg
Temperature Specifications
– Operating Temperature: -20°C to +60°C
– Storage Temperature: -40°C to +85°C
– Insulation Class: F (max. 155°C winding temperature)
Electrical Specifications
– Rated Voltage: 480V AC (3-phase)
– Nominal Current: 8.5A
– Peak Current: 25.5A
– Rated Power: 3.0 kW
– Output Torque: 9 Nm (rated) / 27 Nm (peak)
– Speed Range: 0–5000 RPM
– Encoder Resolution: 20-bit absolute encoder
– Insulation Voltage: 2500V AC
– Protection Class: IP65 (front) / IP54 (connector)
Key Features
– High precision position control with micron-level accuracy
– Fast dynamic response with millisecond-level reaction time
– High torque density and compact mechanical design
– Opto-isolated signal interfaces for anti-interference performance
– Rugged construction for harsh industrial environments
– Compatible with ABB IRC5 robot controllers
Practical Application Cases
1. Automotive Assembly Lines: Integrated into ABB IRB 6700 and IRB 4600 robots for vehicle body welding, painting, and component handling. Provides precise motion control for accurate positioning of welding guns and spray nozzles, improving production efficiency by 20% and reducing defect rates.
2. Electronics Manufacturing: Deployed in pick-and-place robots for semiconductor and PCB assembly. Ensures high-speed, high-precision handling of delicate electronic components, supporting miniaturization and high-density circuit board production.
3. Metalworking & Machining: Used in robotic arms for metal stamping, forging, and CNC machine loading/unloading. Delivers strong torque and stable performance in high-temperature, high-vibration workshops, enabling 24/7 automated operation.
4. Logistics & Packaging: Applied in packaging robots for food, beverage, and consumer goods industries. Enables fast, accurate sorting, palletizing, and wrapping operations, increasing warehouse throughput and reducing labor cost
