A0760GP Emerson Vibration Accelerometer Sensor

Emerson A0760GP English Technical Specification
Basic Information
Brand: Emerson (CSI/EPRO Division)
Model: A0760GP
Order Code: A0760GP
Product Name: General Purpose Industrial Vibration Accelerometer Sensor
Country of Origin: United States

HS Code: 9033000090
Dimension: Φ18mm×42.2mm (Dia×Height; Overall 42.2mm height =1.66inch)
Net Weight: 52g (0.052kg /1.8oz)
Input Parameter
1. Excitation Power Input: 19~28VDC constant current power input (standard 2~10mA ICP power supply)
2. Physical Vibration Input: Acceleration input range ±50g peak (±490m/s²); allow max impact shock 5000g peak
3. Ambient Input: Operating ambient temperature input range -54℃ ~ +121℃
Output Parameter
1. Analog Signal Output: Standard sensitivity 101mV/g(±5% tolerance), output voltage proportional to input acceleration; transverse sensitivity ≤7%
2. Frequency Output Characteristic: ±3dB frequency bandwidth 0.5Hz~10kHz; ±5% linear bandwidth 1.2Hz~5kHz
3. Connector Output: 2-pin top exit signal output terminal for connecting D25782 matching cable
Environmental Spec
Storage Temp: -60℃~+130℃; Hermetically sealed, non-condensing humidity 5~95%RH
