EABT3 HIMA Safety Terminal Module

HIMA EABT3 Safety Terminal Module Product Introduction
Brand: HIMA;
Model: EABT3;
Product Name: Safety Terminal Module;
Dimensions: 140mm × 90mm × 35mm;
Weight: Approximately 0.48kg;
Place of Origin: Germany;
HS Code: 85369000;
Operating Temperature: -20°C ~ +60°C;

Storage Temperature: -40°C ~ +85°C;
Relative Humidity: 5% to 95% RH, non-condensing;
Rated Voltage: 24V DC;
Working Current: Max 0.3A;
Power Consumption: 4W;
Input: Field sensor/actuator signal input;
Output: Isolated signal output to safety I/O module, wiring fault alarm output;
Mounting Type: DIN rail mounting;
Protection Class: IP20;
Certifications: TÜV SIL3, CE, UL;
Features: Integrated line fault monitoring, surge protection, screw terminal connection, compact DIN rail installation, wiring fault detection;
Functions: Field signal wiring termination, safety loop line monitoring, surge protection, transmit field signals to HIMA safety I/O modules, detect open/short circuit wiring faults.
