F3 AIO 8/4 01 HIMA HIMatrix Analog I/O Safety Controller

HIMA F3 AIO 8/4 01 HIMatrix Analog I/O Safety Controller Product Introduction
Brand: HIMA;
Model: F3 AIO 8/4 01;
Product Name: HIMatrix Analog I/O Safety Controller;
Dimensions: 205mm × 130mm × 65mm;
Weight: Approximately 1.0kg;
Place of Origin: Germany;
HS Code: 85371011;
Operating Temperature: -20°C ~ +60°C;
Storage Temperature: -40°C ~ +85°C;

Relative Humidity: 5% to 95% RH, non-condensing;
Rated Voltage: 24V DC;
Working Current: Max 0.55A;
Power Consumption: 11W;
Input: 8 channels analog input, support 4-20mA /0-10V;
Output: 4 channels analog output 4-20mA, dual Ethernet communication output, channel fault alarm output;
Communication Interface: Dual RJ45 10/100Mbps Ethernet with integrated switch, SafeEthernet;
Mounting Type: DIN rail mounting;
Protection Class: IP20;
Certifications: TÜV SIL3, CE, UL;
Features: 8AI +4AO integrated safety controller, 12-bit high resolution, per-channel loop diagnosis, dual Ethernet, hot swappable, support NAMUR sensor supply;
Functions: Analog signal acquisition from field transmitters, safety analog control signal output for control valves, analog loop fault detection, execute safety logic, communicate via SafeEthernet with other HIMatrix nodes.
