F3 DIO 16/8 HIMA HIMatrix Digital I/O Safety Controller

HIMA F3 DIO 16/8 HIMatrix Digital I/O Safety Controller Product Introduction
Brand: HIMA;
Model: F3 DIO 16/8;
Product Name: HIMatrix Digital I/O Safety Controller;
Dimensions: 205mm × 130mm × 65mm;
Weight: Approximately 1.02kg;
Place of Origin: Germany;
HS Code: 85371011;
Operating Temperature: -20°C ~ +60°C;
Storage Temperature: -40°C ~ +85°C;

Relative Humidity: 5% to 95% RH, non-condensing;
Rated Voltage: 24V DC;
Working Current: Max 0.58A;
Power Consumption: 11.5W;
Input:16 channels 24V DC digital input;
Output:8 channels digital safety output, dual Ethernet communication output, channel fault alarm output;
Communication Interface: Dual RJ45 10/100Mbps Ethernet, SafeEthernet;
Mounting Type: DIN rail mounting;
Protection Class: IP20;
Certifications: TÜV SIL3, CE, UL;
Features:16DI+8DO safety I/O, per-channel wire break/short detection, dual Ethernet built-in switch, hot swappable, line monitoring function;
Functions: Collect discrete digital signals from field safety switches and valve feedback, output safety on/off signals to solenoid valves and relays, channel fault diagnosis, run safety interlock logic, communicate over SafeEthernet safety network.
