F3231 HIMA 16-Channel Digital Input Module

HIMA F3231 16-Channel Digital Input Module Product Introduction
Brand: HIMA;
Model: F3231;
Product Name: 16-Channel Digital Input Module;
Dimensions:230mm ×185mm ×28mm;
Weight:Approximately 1.10kg;
Place of Origin:Germany;
HS Code:85371011;
Operating Temperature:-20°C ~+60°C;
Storage Temperature:-40°C ~+85°C;
Relative Humidity:5% to 95% RH, non-condensing;

Rated Voltage:24V DC;
Working Current:Max 0.60A;
Power Consumption:12W;
Input:16 channels digital contact input;
Output:Digital status data output to safety backplane bus, channel fault alarm output;
Communication Interface:HIMA safety backplane bus;
Mounting Type:19-inch rack slot mounting;
Protection Class:IP20;
Certifications:TÜV SIL3, CE, UL, ATEX;
Features:16 high density DI channels, per-channel wire break/short circuit diagnosis, hot swappable, surge protection, safety backplane communication;
Functions:Field discrete safety signal acquisition, valve and safety switch status monitoring, wiring fault detection, transmit digital status data to HIMA safety controller for safety interlock calculation.
