F3322 HIMA 16-Channel Digital Output Module

HIMA F3322 16-Channel Digital Output Module Product Introduction
Brand: HIMA;
Model: F3322;
Product Name:16-Channel Digital Output Module;
Dimensions:230mm ×185mm ×28mm;
Weight:Approximately 1.14kg;
Place of Origin:Germany;
HS Code:85371011;
Operating Temperature:-20°C ~+60°C;
Storage Temperature:-40°C ~+85°C;
Relative Humidity:5% to 95% RH, non-condensing;

Rated Voltage:24V DC logic power, field output 24V DC;
Working Current:Max 0.64A;
Power Consumption:12.6W;
Input:Safety control command input via safety backplane bus;
Output:16 channels digital safety output, output loop fault alarm output;
Communication Interface:HIMA safety backplane bus;
Mounting Type:19-inch rack slot mounting;
Protection Class:IP20;
Certifications:TÜV SIL3, CE, UL, ATEX;
Features:16 high density DO channels, per-channel output circuit diagnosis, hot swappable, short-circuit protection, safety fail-safe output characteristic;
Functions:Execute safety shutdown commands, drive field safety solenoid valves and relays, monitor output loop health, detect circuit faults, report alarm status to safety controller.
