PEDL1000-57941101 GE Delta Module

GE PEDL1000-57941101
Brand: GE
Model: PEDL1000-57941101
Product Name: Liquid-Cooled Power Electronic Delta Module
Country of Origin: United States
HS Code Reference: 85044099 (Industrial liquid-cooled power conversion module for drive systems; final classification subject to official customs verification)
Technical Parameters
Overall dimension: 362 mm (Height) × 225 mm (Width) × 148 mm (Depth)
Net weight: 12.6 kg
DC link rated voltage: 975 V DC

Maximum continuous output current: 733 A
Switching frequency range: up to 1.25 kHz PWM
Cooling method: Liquid cooling, coolant inlet temperature range 5 °C to 40 °C
Operating ambient temperature: 0 °C to +50 °C, derating required above 1000 m altitude
Relative humidity: 5% to 95%, non-condensing
Internal built-in functions: Overvoltage protection, overcurrent protection, overtemperature protection, short-circuit protection, real-time temperature monitoring and fault signal output
Communication interface: Internal module bus for status data transmission with drive controller
Mechanical design: Reinforced metal housing, standard rack mounting form
Insulation grade: Industrial high-voltage insulation compliant with IEC relevant standards
Core functions: AC-DC-AC power conversion, three-phase delta topology power output, motor drive energy conversion, real-time operating status feedback and multi-level fault protection
