ABB RTU560 1KGT036300R0002 Technical Specification
Basic Information
Brand: ABB
Model: RTU560
Order Code: 1KGT036300R0002
Product Name: Modular Remote Terminal Unit Main Control Module (CMU Unit for Substation Automation SCADA System)
Country of Origin: Switzerland
HS Code: 8538909900
Dimension(W×H×D): 218mm × 90mm × 56mm
Net Weight: 0.80kg
Input Parameters
1. Power Input: Rated DC24~60V input (±10% tolerance), compatible with redundant dual power supply access, typical power consumption 7W.
2. Field Signal Input: Expandable via backplane bus to receive external DI/AI module signals; digital input: DC24V passive dry contact/active sourcing signal; analog input: standard 4~20mA / 0~10VDC field transducer signal, max expand up to 256 digital points and 64 analog points.
3. Communication Input: 2×10/100Base-T Ethernet port, 4 configurable RS232/RS485 serial ports for upstream master station data receiving and downstream slave device polling signal input; 1×USB port for local configuration and firmware upgrade.
4. Synchronization Input: Supports IRIG-B, SNTP and PPS time synchronization signal access for system clock calibration.
Output Parameters
1. Internal Bus Output: Backplane I/O bus signal output to drive extended DI/DO/AI/AO peripheral modules for field equipment control.
2. Communication Output: Ethernet & serial interface output, transmits collected field data to upper SCADA/EMS system via IEC104, DNP3, Modbus TCP/RTU, Profibus multiple protocols.
3. Auxiliary Power Output: Built-in isolated DC24V auxiliary power output (max 0.5A) for peripheral relay modules power supply.
4. Status Indicator Output: Onboard multi
