GE UR6EH & UR6NH Product Specification
Basic Information
Brand: GE (General Electric Multilin)
Model: UR6NH
Order Number: UR6NH
Product Name: Horizontal Digital I/O Module
Origin: Canada
HS Code: 8538909000
Dimensions: 186mm × 115mm × 42mm
Weight: 1.00kg
Input & Output Electrical Parameters
Input
1. Control Power Input: 24~48VDC wide range DC power supply, rated current 410mA, power consumption ≤11W
2. Field Digital Input: 8-channel isolated DI, support wet/dry contact dual signal mode
3. Backplane internal bus command input from master protection unit
Output
1. Relay Digital Output: 4-channel Form-A relay contact output
2. Contact Rating: 250VAC/7A, 30VDC/5A per channel
3. Output short-circuit protection built-in each channel
4. Communication feedback output via rack backplane bus
5. Channel operation and fault LED indicator output
Common Environmental Specification
Operating Temperature: -40℃ ~ +70℃
Storage Temperature: -40℃ ~ +85℃
Working Humidity: 5%~95% RH, non-condensing
Protection Class: IP20
Mounting Mode: Standard cabinet rack plug-in installation
EMC Standard: IEC 61000-6-2 industrial anti-interference certification
